TruSeal Accessories

LOCKNUTS

CMP polyamide and nickel-plated brass locknuts have been specifically designed for the TruSeal range to secure the cable gland into non-threaded
enclosures. Cable glands can be purchased with or without locknuts depending on specific needs and are available with metric or NPT threads.

ENTRY THREAD SEALS

To maintain the Ingress Protection rating between the equipment and the cable gland, it may be necessary to fit an approved entry thread sealing washer at the equipment-to-gland entry interface.

The need for a sealing washer will depend on the ingress protection rating, code of protection of the equipment and the type of entry holes available within that equipment. For example, when using Ex e equipment or terminal enclosures (which are permitted to have untapped through-clearance holes) it will be necessary to fit a sealing washer to ensure the minimum IP54 requirement is met. Other equipment with tapped entry holes may not require a sealing washer to maintain the IP54 minimum rating.

CMP recommends using TruSeal approved entry thread sealing washers for all installations where an IP rating of IP55-69K is required; these are provided as standard with all polymer TruSeal cable glands.

0-RING INTERFACE SEALS

For the TruSeal metallic range an O-ring interface seal is provided as standard negating the need for an entry thread sealing washer. O-rings are rated IP66-69K.

Other optional accessories are available from CMP. These can be ordered with the gland or separately if required using the order references in the table below.

UKEX Certificate CML 21UKEX3264X

METRIC
PRODUCT
LOCKNUT OPTIONAL
LOCKNUT**
EMC
LOCKNUT
TRANSIT
DISC
PLUG*** EARTH TAGSERRATED
WASHER
SHROUD
12TSM/Z/X12LN512EMCLN512TD12TSPLUG12ET512SW4
16TSM/Z/X16LN516EMCLN516TD16TSPLUG16ET516SW4
20TSM/Z/X20LN520EMCLN520TD20TSPLUG20ET520SW4LSF04/PVC04
25TSM/Z/X25LN525EMCLN525TD25TSPLUG25ET525SW4LSF06/PVC06
32TSM/Z/X32LN532EMCLN532TD32TSPLUG32ET532SW4LSF10/PVC10
40TSM/Z/X40LN540EMCLN540TD40TSPLUG40ET540SW4LSF13/PVC13
50TSM/Z/X50LN550EMCLN550TD50TSPLUG50ET550SW4LSF16/PVC16
63TSM/Z/X63LN563EMCLN563TD63TSPLUG63ET563EW4LSF19/PVC19
12TSPTSP12LN*12LN512TD12TSPLUG12SW4
16TSPTSP16LN*16LN516TD16TSPLUG16SW4
20TSPTSP20LN*20LN520TD20TSPLUG20SW4
25TSPTSP25LN*25LN525TD25TSPLUG25SW4
32TSPTSP32LN*32LN532TD32TSPLUG32SW4
40TSPTSP40LN*40LN540TD40TSPLUG40SW4
50TSPTSP50LN*50LN550TD50TSPLUG50SW4
63TSPTSP63LN*63LN563TD63TSPLUG63EW4
12TSPV0TSPV012LN*12LN512TD12SW4
16TSPV0TSPV016LN*16LN516TD16SW4
20TSPV0TSPV020LN*20LN520TD20SW4
25TSPV0TSPV025LN*25LN525TD25SW4
32TSPV0TSPV032LN*32LN532TD32SW4
40TSPV0TSPV040LN*40LN540TD40SW4
50TSPV0TSPV050LN*50LN550TD50SW4
63TSPV0TSPV063LN*63LN563TD63EW4
